Heavy-duty Cable Spool Dereeling Machine

  • Model:KS-W240
  • Net. Weight:
  • Dimension:

This is a powerful cable feeding system for reels weighing up to 100Kg with diameter ranging from 300mm to 600mm, it provides a constant tension to downstream wire processing machines, the feeding process allows rapid acceleration of the spool while maintaining low forces on the material being fed.

  • Thanks to the closed loop concept the cable prefeeder can be integrated easily in o a processing line as a stand-alone system.

  • A moveable dancer pulley allows the prefeeder to easily respond to the typical intermittent starting and stopping actions associated with automatic wire processing machines.

  • It has a large wire accumulation capacity, the pulley block can store up to 4m wires in advance to ensure high speed prefeeding condition.

  • The cable dereeler uses a shaftless design for easy loading and unloading of reels.

Download: (1) (2)

Scope of Application: wire reel
Available Wire Size: Φ0.5~10mm
Wire Spool Diameter: 300 ~ 600mm
Wire Spool Width: Max. 400mm
Wire Spool Weight: Max. 100Kg
Wire Feeding Speed:
Storage Capacity: about 4m
Power Supply: 220V 50/60Hz
Net. Weight: 78Kg
Dimensions: 800×680×1000mm

Note: Conforms to the relevant CE directives on machine safety and electromagnetic compatibility.
