Multi-core Cable Cutting and Stripping Machine

  • Model:KS-W1022
  • Brand:KINGSING
  • Price:

This machine is a large-scale power supply sheathed cable stripping machine, which is specially designed for processing multi-core round sheathed cables.

It can process sheathed cables up to 15mm.

The outer sheath and core wire can be stripped simultaneously,

  • supporting the function of core wire automatic trimming,

  • supporting the functions of the outer sheath middle stripping, core wire middle stripping, and core wire half stripping.

Net. Weight:200Kg

Head Strip Length:200mm

Tail Strip Length:100mm

Program Storage:Max.100

Wire Diamete:r415mm

Air Pressure:0.50.7MPa


Power Supply:AC220V/110V 50/60 HZ

Cut Length:180999999mm  (If the tail is not stripped, the minimum cutting range is unlimited)
