This series is a semi-automatic wire stripping, twisting and tinning machine, suitable for processing various double wires, multi-core sheathed wires, rubber wires, etc. This machine needs to be customized according to the product, and there are multiple sub-models to choose from (see technical parameters for details). For double wires, it can realize automatic wire separation, wire stripping, twisting, and tinning; for multi-core sheathed wires, it can realize functions such as automatic sheath stripping, core wire stripping, twisting, tinning, and head trimming.
| Model | KS-W22HA | KS-W22HB | KS-W22HC | KS-W22HD |
| Applicable wire | double wires | Sheathed wire within 3 cores | 4~6 core sheathed wire | Rubber wire within 3 cores |
| Sheath stripping | ≤50mm (splitting wire length) | ≤80mm（Can be customized） | ≤50mm（Can be customized） | ≤50mm（Can be customized） |
Applicable wire: double wire, flat sheathed wire, round sheathed wire
Applicable wire diameter: AWG28~16 (0.1~1.0mm2)
Tinning length: 2~9mm
Production efficiency: 1600~2000 pieces/hour
Operation interface: color touch screen
Air pressure requirement: 0.5~0.7Mpa
Working voltage: 220V 50/60Hz
Net weight: 300kg
Dimensions: 1100*630*1300mm
Note：
The above specifications are for reference only. In the case of extremely hard, tough wires, processing may not be possible even within the cross section range. In case of doubt, KINGSING will be happy to provide processing samples of your wires.
Conforms to the relevant CE directives on machine safety and electromagnetic compatibility.
