Wire Cutting and Bending Machine

  • Model:KS-W061Z
  • Net. Weight:
  • Dimension:

This machine is an automatic bending and stripping machine, which can bend the wire at a certain angle clockwise or counterclockwise in a two-dimensional plane. Parameters such as the direction of the folded wire, the angle of the folded wire, the position of the folded wire, and the length of each section can be directly set in the program. The advantage of this machine is that the bender is close to the knife holder and supports bending of short wires.

Applicable core area: 0.1 - 6.0mm²

Catheter maximum diameter: Φ10mm

Cutting length: 1mm - 100m

The length of the shortest folding distance side: 2.5mm

Stripping length: wire head 0 - 20mm, wire tail can only be half stripped

Cutting tolerance: ±(0.002×L) (L means cutting length)

Stripping speed: 2000-3000 strips/hour

Display mode: full Chinese LCD display

Memory function: up to 99 groups of programs can be stored

Layer stripping function: up to 2 layers of stripping

Drive mode: two-wheel drive

Blade material: tungsten steel knife

Foldable: U-shape, Z-shape, clockwise/counterclockwise

Bending angle adjustable range: 30 degrees, 45 degrees, 60 degrees, 90 degrees

Suitable for stripping wire: PVC, Teflon, glass wire

Working voltage: 220V/50Hz 110V/60Hz

Rated power: 650W

Net weight: 40Kg

Dimensions: 420 × 390 × 280mm


  • The above specifications are for reference only. In the case of extremely hard, tough wires, processing may not be possible even within the cross section range. In case of doubt, KINGSING will be happy to provide processing samples of your wires.

  • Conforms to the relevant CE directives on machine safety and electromagnetic compatibility.
